Perairan Batam, Pulau Sambu. Currently only be marketed in the region of Batam area for hourly, short term or long term project. Special project can be tailored for the users demand. Usually used for Tug Assist in Batam.
Specification
Owner
PT Pelabuhan Tiga Bersaudara
Vessel Name
SENTOSA 3201 (Ex. Koyo Maru No.8)
Type
Tug Boat
Flag
Indonesia
Call Sign
YD 4863
Class
BKI
Build
Year 1983 – Rebuilt 1998. ME both side and Hull/Bridge has been reconditioned totally on 2005
Builder
Daiko Dock Co.Ltd.
Hull Material
Steel
GT/NT
274 / 83
LOA
28.32 M
Beam
9.50 M
Depth
4.00 M
Draft
3.00 M
Main Engine
3200 PS (1600 PS x 2) Rpm 780 Daihatsu DSM 26 8 M
Reduction Gear Box
Gear Ratio 2.64189 : 10
Propeller
4 blades HBSCI 2135 x 2035 Kamome Duck Propeller 360 Degree Circling Daihatsu (Fyg, same as Niigata Z peller ).
Speed
11,00 knots
Windlass
3 T/ 15 M x 122 kw Mitsubishi Heavy Industries
Supercharger
VTR 320
Bollard Pull
40 Tons
Rope Rool Winch
1 T/ 20 M x 122 kw
Fire Fighting
1 set Quarter FIFI /150m³/hour
Nautical Apparatus
Magnet Compass (Have as Radar due to operating In smeeth water area), GPS.
Life Saving
Live Raft LP 12 for 12 persons x 2 unit Live buoy SK 1 X 2 pcs, Life jacket P 436 x 17 pcs.
Each Tank Capacity
Fuel oil No. 18,43 x 2 No. 213,61 x total 54,92 m³ Lub oil ( Centro ) 7, 69 m³
Fresh Water No: 16,63 No: 27,11 x 2 total 60,85 m³.
Water Ballast ( FPT ) 13,53 m³
Auxillary Engine
100 PS 1200 Rpm x 2 units 5 KL Yanmar
Generator
ACNTARS-VC Nishishiba Electric 85 kva x 1200 Rpm x 445 v x 2 unit
Bunker Consumption
8,00 T /day on speed 10,00 knots
Communication Radio
SSB, VHF, HP
Echosounder
Furuno FEC 6210, 300 meter
Air Compressor
30 kg cm² with diesel x 2 unit Matsubara 92A 30 kg cm² with Manual x 1 unit for Propeller 360 Degree Circling Daihatsu (for emergency)
